AMXRacing multifunction charger AMC100

Product detailed description

Quality, professional 100W charger/discharger with 220V and 11-18V connection (XT60). The charger is suitable for the following types of batteries: Li-Po, Li-Fe, Li-Ion/Li-HV batteries (cells 1-6), NiCd/NiMH batteries (cells 1-15), lead-acid batteries 2-20V (1- 10 articles). In addition, the charger has a connection for a temperature sensor, a mini USB-PC connection and a 5V/2.1A USB output. The overall operation of the charger is simple and intuitive. It also provides a very high balancing current for cells that have a drift of almost 500mA per cell!

Features:

• Charging capacity 100W/10A
• Option 12V / 220V (11-18V DC via optional connecting cable XT60)
• USB output
• Memory for up to 10 battery profiles
• Connection for temperature sensor
• Integrated battery tester
• Measurement of internal resistance in the unit

Technical data:

• Length: 135 mm
• Width: 95 mm
• Height: 61 mm
• AC input voltage: 100-240V
• DC input voltage: 11.0-18.0V
• Charging power: Max. 100 W
• Discharge power: Max. 10W
• Charging current: 0.1-10.0A
• Discharge current: 0.1-5.0A
• Balance current: Max. 500 mA/cell
• Lithium batteries: Li-Po, Li-Ion, Li-Fe, Li-HV 1-6 cells
• Nickel batteries: NiCd/NiMh 1-15 cells
• Lead-acid batteries: 2-20V (1-10 cells)
• Battery memory: 10
• Weight: 440 g
• Memory profiles: 10

Package contents: AMC100 charger, Network cable, Charging cable with T-DEAN connector, Balancer, DE/EN manual
